The SDH2103U is high voltage N-type power MOSFET and IGBT half bridge driver, whose built-in undervoltage lockout prevents the power device from working under low control voltage, and high/low side input interlock protection and internal dead time avoids the simultaneous conduction of both high side and low side MOSFETs.

Main feature
  • High-side floating supply absolute voltage:600V

  • Output current:+0.35A / -0.70A

  • 3.3V / 5V / 15V input logic compatible

  • Built-in dead time

  • High-/low-side interlock protection

  • Under-voltage (UV) lockout

  • dV/dt immune

Ordering Information
Product Name Package form Marking Hazardous Substance Control Packing Type Remarks
SDH2103U SOP-8-225-1.27 SDH2103U Halogen free Tape&Reel
SDH2103UTR SOP-8-225-1.27 SDH2103U Halogen free Tube
Block Diagram


Documents
title Types of Size (KB) date Download the latest English version
SDH2103U Datasheet PDF 247 2020-06-11 SDH2103U Datasheet_1.0
