SD8524H is a high-performance, fast turn-off synchronous rectifier controller with a built-in 100V MOSFET. It replaces diode rectifiers for high efficiency in high-performance isolated power supply topology application. It can work with the flyback controller in CCM, DCM, QR modes.

SD8524H can be powered by the high-voltage winding or the output voltage in the flyback converter applications. A slew rate detection circuit prevents the SD8524H from turning on falsely during resonance operation.

The SD8524H is available in SOP8 package.


Main feature

Integrated high-performance MOSFET (100V, 15mΩ)

Supports both high-side and low-side synchronous rectification applications

Supports DCM, CCM, and QR operations

Slew rate detection prevents false turn-on during resonance operation

Powered by the high-voltage winding or the output voltage

250μA standby current

SOP8 package


Ordering Information
Product Name Package form Marking Hazardous Substance Control Packing Type Remarks
SD8524H SOP-8-225-1.27 SD8524H Halogen free Tube
SD8524HTR SOP-8-225-1.27 SD8524H Halogen free Tape & Reel
Block Diagram

SD8524H 英文 (4500&1725).png
