SD8525L is a high-performance, fast turn-off synchronous rectifier controller with a built-in 60V MOSFET. It replaces diode rectifiers for high efficiency in high-performance isolated power supply topology application. It can work with the flyback controller in CCM, DCM, QR modes.

SD8525L can be powered by the high-voltage winding or the output voltage in the flyback converter applications. A slew rate detection circuit prevents the SD8525L from turning on falsely during resonance operation.

The SD8525L is available in SOP8 package.


Main feature
  • Integrated high-performance MOSFET (60V, 10mΩ)

  • Supports both high-side and low-side synchronous rectification applications

  • Supports DCM, CCM, and QR operations

  • Slew rate detection prevents false turn-on during resonance operation

  • Powered by the high-voltage winding or the output voltage

  • 250μA standby current

  • SOP8 package


Ordering Information
Product Name Package form Marking Hazardous Substance Control Packing Type Remarks
SD8525L SOP-8-225-1.27 SD8525L Halogen free Tube
SD8525LTR SOP-8-225-1.27 SD8525L Halogen free Tape&Reel
Block Diagram

SD8525L 英文(PS ).png
