SLP74LVC16373A
5V 16-BIT D-TYPE TRANSPARENT LATCH WITH 3-STATE OUTPUTS
Description Main feature Product specification classification Internal block diagram Technical documentation Relevant package outline drawing

    The SLP74LVC16373A device is a 16-bit transparent D-type latch which is designed for 1.2V to 3.6V VCC operation. One Latch Enable (LE) input and one Output Enable  (OE(———))  are provided for each octal. Inputs can be driven from either 3.3V or 5V devices. When disabled, up to 5.5 V can be applied to the outputs. These features allow the use of these devices in mixed 3.3V and 5V applications.

   The device consists of two sections of eight D-type transparent latches with 3-state true outputs. When LE is HIGH, data at the Dn inputs enter the latches. In this condition, the latches are transparent, that is, the latch outputs change each time its corresponding D-input changes. The latches store the information that was present at the D-inputs one set-up time (tsu) preceding the HIGH-to-LOW transition of LE. When  (OE———)  is LOW, the contents of the eight latches are available at the outputs. When  (OE———)  is HIGH, the outputs go to the high impedance OFF-state. Operation of the  (OE———)  input does not affect the state of the latches.


Main feature

  • Operates from 1.2V to 3.6V

  • Inputs Accept Voltages to 5.5V

  • Supports Mixed-Mode Signal Operation (5V Input and Output Voltages With 3.3V VCC)

  • Multibyte flow-through standard pinout architecture

  • CMOS low power consumption

  • Direct interface with TTL levels

  • ESD protection:

  • HBM exceeds 2000V

  • CDM exceeds 1000V

  • Latch-up performance exceeds 250 mA

  • Specified from -40°C to +85°C and from -40°C to +125°C


Ordering Information
Product Name Package form Marking Hazardous Substance Control Packing Type Remarks
SLP74LVC16373AJZ TSSOP-48-300-0.5 LVC16373A Halogen free Tube
SLP74LVC16373AJZTR TSSOP-48-300-0.5 LVC16373A Halogen free Tape & Reel
Block Diagram

SLP74LVC16373A （2880&1440）.png

Documents
title Types of Size (KB) date Download the latest English version
SLP74LVC16373A 0 1970-01-01 SLP74LVC16373A Brief Datasheet
