     The SLP74LVC1G126 provides one non-inverting buffer/line driver with 3-state output. The 3-state output is controlled by the output enable input (OE). The output is disabled when the output-enable (OE) input is high.

     This bus buffer gate is designed for 1.65V to 5.5V VCC operation.

     This device is fully specified for partial power-down applications using IOFF. The IOFF circuitry disables the output, preventing the damaging backflow current through the device when it is powered down.


Main feature
  • Supports 1.65V to 5.5V VCC operation

  • Input accept voltages up to 5V

  • ±24mA output drive (VCC=3.0V)

  • CMOS low power consumption

  • ESD protection:

  • HBM exceeds 2000V

  • CDM exceeds 1000V

  • Latch-up performance exceeds 100mA

  • Specified from -40°C to +85°C and from -40°C to +125°C


Ordering Information
Product Name Package form Marking Hazardous Substance Control Packing Type Remarks
SLP74LVC1G126KMTR SOT-353-5L SF Halogen free Tape & Reel
Block Diagram

SLP74LVC2G04 英文(1440&720).png

Documents
title Types of Size (KB) date Download the latest English version
SLP74LVC1G126 0 1970-01-01 SLP74LVC1G126 Brief Datasheet
