SD20A60FA8
INTELLIGENT POWER MODULE(IPM), 3 PHASE FULL-BRIDGE 600V/20A

    SD20A60FA8 is a highly integrated and highly reliable three-phase brushless DC motor drive circuit, which is mainly used in medium and lower power frequency conversion drives, such as air conditioners, dishwashers, industrial sewing machines, etc. It contains 6 fast recovery power MOSFETs and 3 half-bridge HVIC for gate driving. It has 6 low-loss IGBT transistors and 3 high-speed half-bridge high-voltage gate driver circuits.

    SD20A60FA8 integrates various protection functions such as undervoltage, short circuit, and overtemperature, providing excellent protection and a wide safe operating range. Since each phase has an independent negative DC terminal, its current can be sensed separately.

    SD20A60FA8 is designed with good insulation and perfect thermal properties. It is compact and suitable for built-in motors or any other applications requiring the compact installation.


Main feature
  • Built-in six 600V/20A low power IGBT

  • Built-in high-voltage Gate driver circuit (HVIC)

  • Built-in under voltage protections, over temperature/over current protection

  • Compatible with 3.3V, 5V MCU interface, active high

  • Three independent negative DC terminals for inverter current detection

  • Alarm signal: low-side under-voltage protection and short-circuit protection;

  • DBC design, low thermal resistance;

  • Insulation class: 2500Vrms/min


Ordering Information
Product Name Package form Marking Hazardous Substance Control Packing Type Remarks
SD20A60FA8 DIP-27H SD20A60FA8 Halogen free Tube
Block Diagram


Documents
title Types of Size (KB) date Download the latest English version
SD20A60FA8 0 1970-01-01 SD20A60FA8 Brief Datashet
