    SD7558C is the dimming signal conversion IC, it integrates 5VLDO, which simplifies the peripheral circuit. The input signal can be 0~10V, PWM or potentiometer which can be converted to PWM output. The smooth output is well suitable for LED dimming and excellent user experience.

Main feature
  • VIN input range: 15V~95V

  • Integrated 5VLDO

  • 0~10V, PWM or potentiometer can be converted to PWM output

  • current source: 100µA

  • Over temperature protection


Ordering Information
Product Name Package form Marking Hazardous Substance Control Packing Type Remarks
SD7558C SOP-8-225-1.27 / Halogen free Tube
SD7558CTR SOP-8-225-1.27 / Halogen Free Tape & Reel
Block Diagram


Documents
title Types of Size (KB) date Download the latest English version
SD7558C 0 1970-01-01 SD7558C Brief Datasheet
