    The SDH752XHN is a high performance, critical conduction mode under high load and discontinuous conduction mode under light load , power factor correction (PFC) controller. It has built-in MOSFETs of different models.

    SDH752XHN adopts high voltage power supply, and omits auxiliary winding by adopting MOS gate zero crossing detection technology.

    It uses patented COMP-saving capacitor technology to achieve excellent power factor correction and constant voltage output with only a few peripheral components, which greatly reduces the system cost.

    It provides various protections, such as output over voltage protection, output under voltage protection, CS cycle-by-cycle current limit and over temperature protection etc.


Main feature
  • Single winding inductor booster system with reduced periphery

  • High voltage start-up and power supply

  • Built-in high-voltage MOSFET

  • Gate Zero-crossing detection and critical conduction mode

  • Fixed on time control

  • Light load frequency reduction control

  • Patented closed-loop control technology, without peripheral compensation network, anti-moisture and anti-leakage

  • VCC under-voltage lockout

  • Output overvoltage protection   and  output under voltage protection

  • CS cycle-by-cycle current limit

  • Over temperature protection


Ordering Information
Product Name Package form Marking Hazardous Substance Control Packing Type Remarks
SDH7524HN EHSOP-5-325-1.7 7524HN Halogen free Tube
SDH7524HNTR EHSOP-5-325-1.7 7524HN Halogen free Tape&Reel
Block Diagram


Documents
title Types of Size (KB) date Download the latest English version
SDH752XHN 0 1970-01-01 SDH752XHN Brief Datasheet
