    SDM05A120TA is a highly integrated and highly reliable three-phase brushless DC motor drive circuit, which is mainly used in low-power frequency conversion drives, such as air conditioner fan, etc. It contains 6 low loss IGBTs and 3 half-bridge HVIC for gate driving.

    SDM05A120TA integrates various protection functions such as undervoltage and short circuit, as well as temperature output, providing excellent protection and a wide safe operating range. Since each phase has an independent negative DC terminal, its current can be sensed separately.

    SDM05A120TA is designed with good insulation and perfect thermal properties. It is compact and suitable for built-in motors or any other applications requiring the compact installation.


Main feature
  • Built-in six 1200V/5A low loss IGBTs

  • Built-in high-voltage Gate driver circuit (HVIC)

  • Built-in under voltage protections, over current protection and temperature output

  • Built-in bootstrap diode

  • Compatible with 3.3V, 5V MCU interface, active high

  • Three independent negative DC terminals for inverter current detection

  • Alarm signals: corresponding to low-side undervoltage protection, , and short-circuit protection

  • Package: Utilizes a Direct Bonded Copper (DBC) design, which provides an exceptionally low thermal resistance.

  • Insulation class: 2500Vrms/min


Ordering Information
Product Name Package form Marking Hazardous Substance Control Packing Type Remarks
SDM05A120TA DIP-27H SDM05A120TA Halogen free Tube
Block Diagram


Documents
title Types of Size (KB) date Download the latest English version
SDM05A120TA 0 1970-01-01 SDM05A120TA Brief Datasheet
