SDM06V60TA3
INTELLIGENT POWER MODULE(IPM), 3 PHASE FULL-BRIDGE 600V/6A

    SDM06V60TA3 is a highly integrated and highly reliable three-phase brushless DC motor drive circuit, which is mainly used in lower power frequency conversion drives, such as fans, pumps, Refrigerator,etc. It contains 6 low loss IGBTs and 3 half-bridge HVIC for gate driving.

    SDM06V60TA3 integrates various protection functions such as undervoltage, short circuit, and overtemperature, as well as temperature output, providing excellent protection and a wide safe operating range. Since each phase has an independent negative DC terminal, its current can be sensed separately.

    SDM06V60TA3 is designed with good insulation and perfect thermal properties. It is compact and suitable for built-in motors or any other applications requiring the compact installation.


Main feature
  • Built-in six 600V/6A low loss IGBTs

  • Built-in high-voltage Gate driver circuit (HVIC)

  • Built-in under voltage protections, over current protection and temperature output

  • Built-in shut-down input

  • Built-in inter-lock function

  • Built-in bootstrap diode

  • Compatible with 3.3V, 5V MCU interface, active high

  • Three independent negative DC terminals for inverter current detection

  • Insulation class: 1500Vrms/min


Ordering Information
Product Name Package form Marking Hazardous Substance Control Packing Type Remarks
SDM06V60TA3 DIP-2VC SDM06V60TA3 Halogen free Tube
Block Diagram

SDM06V60TA3 中英文同.png

Documents
title Types of Size (KB) date Download the latest English version
SDM06V60TA3 0 1970-01-01 SDM06V60TA3 Brief Datasheet
