    The SDH21081 is a high voltage N-type power MOSFET and IGBT half bridge driver, whose built-in undervoltage lockout prevents the power device from working under low control voltage, Schmidt trigger circuit is used at the input, which features high noise immunity to ensure that the power tube will not be turned on by noise.

Main feature
  • High-side floating supply offset voltage: 600V

  • Output current: +2.7 A / -3A

  • 3.3V / 5V / 15V input logic compatible

  • Under-voltage lockout (UVLO)

  • dV/dt immune

  • High noise immunity

  • High Side and Low Side Turn-On/Off Delay Matching


Ordering Information
Product Name Package form Marking Hazardous Substance Control Packing Type Remarks
SDH21081 SOP-14-225-1.27 SDH21081 Halogen free Tube
SDH21081TR SOP-14-225-1.27 SDH21081 Halogen free Tape & Reel
Block Diagram


Documents
title Types of Size (KB) date Download the latest English version
SDH21081 0 1970-01-01 SDH21081 Brief Datasheet
