SVS7N65D(F)(MJ)(FJ)D2
SUPER JUNCTION MOS POWER TRANSISTOR

SVS7N65D(F)(MJ)(FJ)D2 is an N-channel enhancement mode high voltage power MOSFETs produced using Silan’s super junction MOS technology. It achieves low conduction loss and switching losses. It leads the design engineers to their power converters with high efficiency, high power density, and superior thermal behavior. Furthermore, it’s universal applicable, for example, it is suitable for hard and soft switching topologies, Lighting, Adapters, etc.


Main feature
  • 7A,650V, RDS(on)(typ.)=0.55W@VGS=10V

  • New revolutionary high voltage technology

  • Ultra low gate charge

  • Periodic avalanche rated

  • Extreme dv/dt rated

  • High peak current capability



Documents
title Types of Size (KB) date Download the latest English version
SVS7N65D(F)(MJ)(FJ)D2 0 1970-01-01 SVS7N65D(F)(MJ)(FJ)D2 Datasheet_1.7
